NVIDIA Jetson:
AI platform for all autonomous machines

High-performance, low-power NVIDIA® Jetson™ modules give you real-time artificial intelligence (AI) performance where you need it most—at the edge. Processing of complex data can now be done on-board small, power-efficient devices, so you can count on fast, accurate inference in network-constrained environments.

NVIDIA Jetson developer kits and modules, together with NVIDIA JetPack SDK, provide everything you need to develop and deploy applications for multiple use cases using one unified software architecture. This dramatically reduces software development costs and gives you a scalable AI strategy for autonomous machines.

AI at the edge unlocks tremendous potential in everything from healthcare to manufacturing to agriculture—and beyond.

Jetson系列模块硬件应用解决方案

北京品立科技有限责任公司作为NVIDIA Jetson系列产品生态链合作伙伴,具有专业的软、硬件开发团队,可以为用户提供基于Jetson全系产品的配套接口载板、加固系统整机,及周边配件产品。


Flexible and scalable Jetson hardware solution

NVIDIA® Jetson™ modules can support a wide range of applications that require a variety of performance levels and prices.For example, network video recorder (NVR), automatic optical inspection (AOI) in high precision manufacturing and autonomous mobile robot (AMR). Jetson series modules are small in shape and can provide excellent performance and energy efficiency. Therefore, modern AI, deep learning and reasoning can be effectively introduced into the embedded system of edge devices.

Jetson Nano
NVIDIA Jetson Nano is a small, powerful computer for embedded AI systems and IoT that delivers the power of modern AI in a low-power platform. Get started fast with the NVIDIA Jetpack SDK and a full desktop Linux environment and start exploring a new world of embedded products.
Jetson TX2
Jetson TX2 is built around an NVIDIA Pascal-family GPU and features a variety of standard hardware interfaces that make it easy to integrate it into a wide range of products and form factors. The Jetson TX2 embedded module for edge AI applications comes in three versions: Jetson TX2, Jetson TX2i, and the lower-price Jetson TX2 4GB.
Jetson Xavier NX
Jetson Xavier NX brings up to 21 TOPs of accelerated AI computing to the edge in a small form factor module. It can run multiple modern neural networks in parallel and process data from multiple high-resolution sensors—a requirement for full AI systems. Jetson Xavier NX is production-ready and supports all popular AI frameworks.
Jetson AGX Xavier
Jetson AGX Xavier series modules enable new levels of compute density, power efficiency, and AI inferencing capabilities at the edge. Users can configure operating modes for their applications at 10W, 15W, or 30W with the Jetson AGX Xavier module. These modules have 10X the energy efficiency and 20X the performance of Jetson TX2.

NVIDIA Jetson Modules Specification Somparison



 Jetson NanoJetson TX2 Series

TX2 4GB TX2TX2i
Jetson AGX Xavier Series

Jetson AGX Xavier 32GBJetson AGX Xavier NX
GPUNVIDIA Maxwell architecture with 128 NVIDIA CUDA® coresNVIDIA Pascal architecture with 256 NVIDIA CUDA coresNVIDIA Volta architecture with 512 NVIDIA CUDA cores and 64 Tensor coresNVIDIA Volta architecture with 384 NVIDIA CUDA cores and 48 Tensor Cores
0.5 TFLOPs (FP16)1.3 TFLOPS (FP16)11 TFLOPS (FP16)
22 TOPS (INT8)
21 TOPS (INT8)
CPUQuad-core ARM®Cortex®-A57 MPCore processorDual-core Denver 2 64-bit CPU and quad-core ARM A57 complex8-core ARM v8.2 64-bit CPU, 8MB L2 + 4MB L36-core ARM v8.2 64-bit CPU, 6MB L2 + 4MB L3
DLA - - 5 TFLOPS (FP16)
10 TOPS (INT8)
4.1 TFLOPS (FP16)
8.2 TOPS (INT8)
Memory4 GB 64-bit LPDDR44 GB 128-bit LPDDR48 GB 128-bit LPDDR432 GB 256-bit LPDDR4x 2133MHz - 137GB/s8 GB 128-bit LPDDR4x 1600MHz - 51.2GB/s
Storage16 GB eMMC 5.116GB eMMC 5.132GB eMMC 5.132GB eMMC 5.116GB eMMC 5.1
Video Encode250MP/sec
1x 4K @ 30 (HEVC)
2x 1080p @ 60 (HEVC)
4x 1080p @ 30 (HEVC)
500MP/sec
1x 4K @ 60 (HEVC)
3x 4K @ 30 (HEVC)
4x 1080p @ 60 (HEVC)
8x 1080p @ 30 (HEVC)
2x1000MP/sec
4x 4K @ 60 (HEVC)
8x 4K @ 30 (HEVC)
16x 1080p @ 60 (HEVC)
32x 1080p @ 30 (HEVC)
2x464MP/sec
2x 4K @ 30 (HEVC)
6x 1080p @ 60 (HEVC)
14x 1080p @ 30 (HEVC)
Video Decode500MP/sec
1x 4K @ 60 (HEVC)
2x 4K @ 30 (HEVC)
4x 1080p @ 60 (HEVC)
8x 1080p @ 30 (HEVC)
1000MP/sec
2x 4K @ 60 (HEVC)
4x 4K @ 30 (HEVC)
7x 1080p @ 60 (HEVC)
14x 1080p @ 30 (HEVC)
2x1500MP/sec
2x 8K @ 30 (HEVC)
6x 4K @ 60 (HEVC)
12x 4K @ 30 (HEVC)
26x 1080p @ 60 (HEVC)
52x 1080p @ 30 (HEVC)
30x 1080p @ 30 (H.264)
2x690MP/sec
2x 4K @ 60 (HEVC)
4x 4K @ 30 (HEVC)
12x 1080p @ 60 (HEVC)
32x 1080p @ 30 (HEVC)
16x 1080p @ 30 (H.264)
Camera12 lanes (3x4 or 4x2) MIPI CSI-2, DPHY 1.1 (1.5 Gbps)12 lanes MIPI CSI-2, D-PHY 1.2 (30 Gbps)16 lanes MIPI CSI-2, 8 lanes SLVS-EC
D-PHY (40 Gbps), C-PHY (109 Gbps)
Up to 6 cameras (36 via virtual channels),
12 lanes MIPI CSI-2,
D-PHY 1.2 (up to 30 Gbps)
Power5W | 10W7.5W | 15W10W | 20W10W | 15W | 30W10W | 15W
ConnectivityWi-Fi requires external chipWi-Fi requires external chipWi-Fi onboardWi-Fi requires external chipWi-Fi requires external chipWi-Fi requires external chip
10/100/1000 BASE-T Ethernet10/100/1000 BASE-T Ethernet10/100/1000 RGMII
Gigabit Ethernet
10/100/1000 BASE-T Ethernet
Mechanical69.6 mm x 45 mm
260-pin edge connector
87 mm x 50 mm
400-pin connector
100 mm x 87 mm
699-pin connector
45 mm x 69.6 mm
260-pin SO-DIMM connector
Jetson Resources
